Product Information
Certification:CE
Place of Origin:China
Warranty:7 years
Description
Power Supply: AC220V±10%, 50Hz±1Hz
Rated Input Power: 500VA
Working Pressure: Continuously adjustable from 0 to 500kPa; Max. output working pressure: 500kPa±10%
8-inch touch screen for real-time display of treatment parameters
Energy Flux Density: 0.01–9 mJ/mm²
Output Frequency: Adjustable from 3 to 15Hz
Energy Stability: Better than ±20%
Total Output Shots per Treatment: 500 to 4000 shots (step of 500 shots)
*9. Power-on password protection. Dedicated device for designated operator to avoid misoperation risks.
*10. 7 types of treatment probes matched with different treatment programs to meet diverse clinical requirements.
Collimated treatment probes: 10mm, 15mm, 15mm high-energy;
Radial / Divergent treatment probes: 20mm, 20mm high-energy, 25mm, 30mm
3-stage anti-slip & shock-absorbing handle to reduce hand fatigue of operators caused by vibration
Shock Wave Generation: Pneumatic ballistic type
Shock Wave Output Mode: Single shot / Continuous
Precision pressure control technology. Real-time adjustment of pressure, frequency and shock shots for personalized treatment.
Counter function: Counting and display function for easy recording of treatment sessions
*16. In custom mode, the system automatically saves the last user settings. No repeated configuration after restart. Pre-set optimal parameters are available for protocol modes, which can be further modified according to specific needs.
*17. Imported core components: Original imported air compressor with strong power and low-noise design; imported solenoid valve for high output stability.
*18. Dual overpressure safety device to prevent sudden pressure rise of air compressor under normal or single fault conditions.
Lateral Epicondylitis (Tennis Elbow)
De Quervain’s Tenosynovitis
Stenosing Tenosynovitis of Flexor Digitorum
Adhesive Capsulitis (Frozen Shoulder)
Subacromial Impingement Syndrome
Calcific Tendinitis of the Shoulder
Tenosynovitis of Long Head of Biceps Brachii
Medial Epicondylitis (Golfer’s Elbow)
Greater Trochanteric Bursitis
Patellar Tip Tendinopathy
Pes Anserine Tendinitis
Prepatellar Bursitis
Patellar Tendinopathy
Medial Tibial Stress Syndrome (Shin Splints)
Plantar Fasciitis
Achilles Tendinopathy
✅ German original imported air compressor for stable power output
