Yunnan Original Color Biomedical Technology Co., Ltd.

1. Power Supply: AC 220V / 50Hz; Input Power: ≤800VA
2. LCD Display: 10.1-inch touch screen for real-time display of treatment parameters
3. Ozone gas concentration: ≥80mg/m³
4. Ozone gas flow rate: 4L/min, tolerance ±20%
5. Ozone water concentration: ≥0.1mg/L
6. Ozone water flow rate: Continuously adjustable from 0~1.5L/min, tolerance ±20%
7. Water outlet pressure: Continuously adjustable from 0MPa~0.1MPa, tolerance ±20%
8. Noise during normal operation: ≤60dB(A)
9. Ozone gas leakage: ≤0.16mg/m³
10. Timer: Adjustable range 0~99min, tolerance ±5%
11. Irrigating fluid heating range: 19℃~39℃, tolerance ±3℃
12. Over-temperature protection: When the temperature of irrigating fluid exceeds 45℃, heating and irrigation functions stop working with audible alarm.
13. Ultrasonic nebulization operating frequency: 1.7MHz, tolerance ±10%
14. Nebulization rate: ≥10mL/h
15. Continuous operating time: ≥8h

Indications: Adjuvant therapy for various gynecological vaginal disorders (vaginitis, cervicitis, cervical ectropion and abnormal vaginal discharge caused by bacterial, fungal, mold, trichomonal pathogens), pelvic inflammatory disease, vulvitis, atrophic vaginitis, and post-operative, post-natal and post-abortion tissue repair.

• Novel and stylish appearance
• Built-in nebulization chamber for improved hygiene, different from common external hanging type on the market
• Large nebulization output for enhanced effects within identical treatment time
• Combined therapy: ozone water irrigation + ozone nebulization + ultrasonic atomized gynecological antibacterial dressing, providing systematic cavity cleaning and bacteriostatic adjuvant treatment
