- Scope of Application: For the treatment of pain and inflammation. It can improve blood circulation, promote tissue repair and regeneration, reduce swelling and accelerate wound healing.
- 10.1-inch color touch screen control. Buttons are user-friendly with clear visual display for convenient operation.
- Infrared Spectrum Range: 590～1400 nm (0.59 μm～1.4 μm).
- Treatment Time: Adjustable from 5 to 95 min with 5 min step increment. Audible alert upon completion of treatment.
- Treatment Intensity: 1~10 adjustable levels, which can be adjusted according to patient tolerance.
★6. Light-emitting outlet area: 100 cm², tolerance ±20%; Effective radiation area: 1000 cm², tolerance ±20%.
★7. Optical power density: Optical power density at the center of light output window ≥0.5 W/cm².
- Working surface temperature: Maximum central temperature is 45℃ at 35 cm from the light output window, tolerance ±3℃.
★10. Electric lifting system: Maximum lifting height of treatment head: 400 mm, tolerance ±20%.
- Treatment angle adjustment: The treatment head can be adjusted horizontally and vertically. Horizontal rotation angle ≥90°, vertical rotation angle ≥90°.
★12. Overheat protection: The therapy device is equipped with dual overheat protection.
★13. Three major safety protections:
a) The light source has an overheat protection device. It will automatically turn off and stop treatment when the light source overheats.
b) Tilt power-off protection. The device cuts off power when tipped over.
c) Distance positioning rod to indicate safe treatment distance.
- Low-noise design: Noise ≤55dB(A) during normal operation.
- Continuous working time: ≥4 hours.
★16. Software copyright with independent intellectual property rights.
★17. Utility model patent certificate with independent intellectual property rights.
- Operating environment: Indoor use in well-ventilated area without corrosive gas.
Ambient temperature: 5℃～40℃;
Relative humidity: ≤80%;
Atmospheric pressure: 70kPa～106kPa;
Power supply: AC 220V±22V, 50Hz±1Hz;
Input power: 750VA.
For the treatment of pain and inflammation. It can improve blood circulation, promote tissue repair and regeneration, reduce swelling and accelerate wound healing.
- Imported halogen filtered light source system
- Near-infrared spectrum 590–1400 nm with high optical power density
- Effective tissue penetration up to 15 cm
- Automatic lifting system
- Built-in tip-over protection & high-temperature power-off safety
