Yunnan Original Color Biomedical Technology Co., Ltd.

1. Power Supply: AC 220V / 50Hz; Input Power: 100VA
2. LCD Display: 10.1-inch touch screen for real-time display of treatment parameters
3. Number of Channels: 4-channel output, supports simultaneous treatment for 4 patients
4. Ultrasound Output: • Operating acoustic frequency: 1MHz, tolerance ±10% • Effective radiation area: 3.8 cm², tolerance ±20% • Maximum output acoustic intensity: 0.1 W/cm², tolerance ±30%
5. Medium-frequency Output: • Fundamental wave: Square pulse wave; Frequency: 2kHz±10%; Pulse width: 250μs±30% • Maximum output current: 18mA, tolerance ±20% • Modulation frequency: 5.6Hz, tolerance ±10%; Modulation depth of low-frequency modulated medium frequency: 100% • Peak-to-peak output pulse voltage: Max. 28V±30%, 50 adjustable levels

★6. Electroporation: • Waveform: Pulse wave • Max. peak-to-peak output voltage: 58V±30% • Number of pulse cycles: 5 • Pulse energy: ≤300mJ

★7. Quick level adjustment: Built-in quick-adjust buttons for fast access to commonly used levels ★8. Compliant with new standards: Test report to IEC 60601-1:2020 9. Continuous working time: ≥6 hours

• Hemiplegia from acute ischemic stroke
• Cerebrovascular sequelae
• Pneumonia, pediatric pneumonia, respiratory tract infection
• Chronic gastritis, gastroenteritis
• Chronic pelvic inflammatory disease, vaginitis and other gynecological inflammations
• Neck, shoulder and low back pain
• Fractures
• Arthritis

• 3-in-1 integrated therapy: Ultrasound, Electroporation & Medium-frequency current for enhanced therapeutic effects
• One of only 4 manufacturers in China with valid registration certificate; rare model approved for cerebrovascular disease treatment
• Combines ultrasound, electroporation and medium-frequency pulse to achieve localized transdermal drug delivery together with physical therapy. Fast, precise and suitable for multiple clinical departments
