- Power Supply: AC 220V / 50Hz; Input Power: 40VA
- LCD Display: 10.1-inch touch screen for real-time display of treatment parameters
★3. Treatment Channels: 2 output channels working independently without mutual interference
- Carrier Waveform: Bidirectional rectangular pulse wave
- Carrier Frequency: Adjustable from 1Hz to 120Hz. Step size 0.5Hz for frequencies below 20Hz; step size 5Hz for 20Hz～120Hz. Tolerance ±5%.
- Carrier Pulse Period: 8.33ms～1000ms, tolerance ±10%
- Carrier Pulse Width: Adjustable from 50µs to 500µs with 50µs step increment, tolerance ±10%
- Modulation Frequency: 0.028Hz～0.5Hz, tolerance ±20%
- Output Current: Max. output current: 50mA, tolerance ±10%
- Output Amplitude: 99 adjustable levels; maximum output amplitude 70V, tolerance ±10%
- Output Current Stability: Variation rate of output current under different loads ≤10%
- Feedback Threshold: 10μV～999μV
★13. Resolution (Measurement Sensitivity): ≤2μV
★14. System Noise: ≤1μV
- Passband: Not narrower than 20Hz～500Hz (-3dB), excluding notch band
- Differential-mode Input Impedance: > [Note: your original text value missing]
★17. Common-mode Rejection Ratio: >100dB
- Timer: Adjustable from 5min to 60min with 5min step increment, tolerance ±5%
★19. Software Functions
a) Neuromuscular Electrical Stimulation: Treatment time and current intensity configurable, multiple treatment protocols optional
b) Muscle Triggered Electrical Stimulation: Configurable treatment time, current intensity and threshold
c) Parameter setting for treatment protocols
★20. The product holds utility model patent, design patent and software copyright. Relevant certificates are available upon request.
It is mainly used for sports rehabilitation, neurological rehabilitation and stroke rehabilitation therapy for pain rehabilitation.
- Freely adjustable supra-threshold and sub-threshold settings to suit individual patients
- Detects muscle signals and executes treatment based on clinical protocols
- Real-time visualization of muscle signals for patients to observe directly
