1. Power Supply: AC 220V / 50Hz; Rated Power: 1200W
2. LCD Display: Touch LCD screen, real-time display of treatment parameters
3. Voice Prompt: Built-in voice guidance throughout operation to avoid misoperation
4. Automatic Timer: Adjustable from 0–99 min with 1 min step; auto power-off upon timeout
5. Automatic Temperature Control: After startup, heating activates when steam temperature is below set value and stops when above set value to maintain stable temperature. Temperature setting range: 42℃~48℃, tolerance ±3℃.
6. Dry-burn Protection: When no liquid is ejected and heater temperature reaches 110℃±5℃, heating stops automatically.
7. Functions: Washing, fumigation therapy and drying a. Washing: Washing time configurable; washing temperature adjustable 30℃–40℃. Water temperature at outlet reaches 37℃±2℃ within 1 min after power-on. Nozzle can be set to columnar stream; flow valve adjustment enables water jet over 1m. b. Fumigation: Herbal vapor fumigation with 3 intensity levels: High 48℃(±3℃), Medium 45℃(±3℃), Low 42℃(±3℃). Time to heat vapor from 25℃ to target temperature ＜15 minutes. c. Drying: 3 temperature levels: High 48℃(±3℃), Medium 45℃(±3℃), Low 42℃(±3℃)
8. Dual safety protection system a. Washing mode: When temperature exceeds default 37℃, the first protection circuit cuts off output. Output resumes once temperature drops below 37℃. If temperature continues rising to 45℃±5℃ due to primary protection failure, the second protection will cut off power supply. b. Fumigation mode: When temperature exceeds set working value, first protection cuts off output. Output resumes after cooling below setpoint. If temperature rises to 50℃±5℃, secondary protection cuts off power. c. Drying mode: When temperature exceeds set working value, first protection cuts off output. Output resumes after cooling below setpoint. If temperature rises to 50℃±5℃, secondary protection cuts off power.
9. Disposable seat cover to prevent cross-infection. Infrared sensor for automatic seat cover rotation; replacement speed: 8 seconds per cycle. Constant temperature seat design.
10. Medicine cup capacity: 500ml±20ml
11. Continuous operating time: ≥8 hours
12. Max load capacity: ≥120kg for 1 hour without deformation
13. Noise level: ≤65dB
14. Qualified medical device with Medical Device Test Report and Medical Device Registration Certificate
15. Granted Design Patent Certificate and Software Copyright Certificate
16. EMC: Complies with national EMC standards; supporting documents available.

Indications: Adjuvant fumigation therapy combined with medication for disorders of human buttocks and perineal region. It can be applied for perianal pruritus, eczema, abscess, hemorrhoids, as well as adjuvant rehabilitation of gynecological conditions.

• Thermal fumigation with electromagnetic mutual inductance suspension heating system, converts liquid medicine into medicinal aerosol for direct action on lesion sites; supports transdermal release for adjuvant bacteriostasis, anti-inflammation and tissue repair
• 3-in-1: warm water washing + thermal fumigation + thermal drying, fully automatic integrated operation
• Auto disposable seat cover replacement, one seat cover for each patient to avoid cross infection
