Technical Specifications
- Temperature: Infusion liquid temperature adjustable within 25℃～40℃, tolerance ±2℃.
- Capacity: Liquid storage tank ≥16L, tolerance ±10%; medicine cup ≥500ml, tolerance ±10%.
- Timer
*3.1 Liquid feeding time: Adjustable 0s～10s, tolerance ±5%.
*3.2 Pause time: Adjustable 0s～10s, tolerance ±5%.
3.3 Working duration: Continuous operation ≥24 hours.
*4. Liquid Volume
4.1 Water filling time: 5–95 min, step 5 min, tolerance ±10%.
4.2 Infusion liquid volume: 0～5000ml, step 10ml, tolerance ±10%.
- Operating noise ≤65dB(A).
*6. Disposable rectal catheter: Qualified product with medical device registration or filing certificate.
*7. Dual safety protection
7.1 When temperature exceeds the set working temperature, the first protection circuit activates and cuts off the liquid output.
7.2 Output resumes after temperature drops below the set value.
7.3 If the first protection fails and temperature rises to 42℃±2℃, the second protection circuit cuts off the power supply.
*8. Dry-burn protection function equipped.
*9. Multimedia playback: Secondary display on main unit supports video, music, image and camera footage playback.
- Automatic pipeline cleaning; inlet water is filtered, disinfected and purified to remove impurities.
- Inlet water filtration precision: 5μm.
*12. Low-temperature protection: The device stops working when inlet water temperature is more than 5℃ lower than the set value.
- Maximum load capacity of treatment bed ≥135kg.
- Total power: 2000W.
*15. Two-piece integrated design for easy movement.
*16. The bed and machine are registered as one integrated medical device; utility model patent and design patent certificates available.
- Qualified medical device with Medical Device Registration Certificate.
*19. Electromagnetic Compatibility (EMC): Complies with national EMC standards.
Indications: Adjuvant use for cleansing enema.
Applied in gastroenterology and proctology departments for bowel preparation, adjuvant rehabilitation of colitis, intestinal obstruction, hemorrhoids and palliative care for advanced colorectal cancer.
For bowel cleansing before abdominal surgery in general surgery.
For TCM colon enema and medicated retention enema.
For colon dialysis and adjuvant management of chronic renal failure in nephrology department.
Adjuvant physical therapy for beauty department for body conditioning.
- Fully automatic computer control + built-in patient data management system, real-time monitoring with alarm alerts
- External water purification module, auto pipeline cleaning, precision filtration and water disinfection
- PID precise temperature control, inflow liquid stabilized at 37℃±1℃
- German imported peristaltic pump, adjustable flow, infusion volume tolerance ±1ml
- Single-use disposable rectal catheter with on-site disposal to prevent cross infection
- Constant-temperature medicated retention enema function; computer-controlled flow mimics natural intestinal peristalsis
- Low-voltage operation, automatic dual water pressure regulation and temperature warning for higher safety
