Yunnan Original Color Biomedical Technology Co., Ltd.

1. Display: 10.1-inch touch screen for real-time display of treatment parameters
2. Power Supply: AC 220V / 50Hz
3. Input Power: 180VA
4. Timer: Adjustable range 5~60 min, step 5 min. Default setting: 20 min upon power-on. ★5. Function Channels: 2 channels for vibration percussion; 1 channel for nebulization
5. Vibration frequency range & output accuracy: a) Manual adult mode: adjustable 10Hz～60Hz, step 1Hz b) Manual pediatric mode: adjustable 10Hz～30Hz, step 1Hz ★7. Applicator heads: ≥11 percussion heads, including ≥6 for adults and ≥5 for pediatric patients Adult heads: 1 rectangular sponge head 200×70mm; 1 round rubber head Φ130mm; 1 concave-center rubber head Φ130mm; 1 round sponge head Φ90mm; 1 round sponge head Φ78mm; 1 round sponge head Φ68mm.

Pediatric heads: 1 round sponge head Φ90mm; 1 round sponge head Φ78mm; 1 round sponge head Φ68mm; 1 round sponge head Φ58mm; 1 round sponge head Φ48mm.

1. Amplitude: Max amplitude of percussion applicator: 5.6mm, tolerance ±20%
2. Flexible drive shaft: 1.8m
3. 12 sputum clearance modes: a) 6 automatic modes for adults b) 6 automatic modes for children

★11. Nebulization function: a) Gas flow rate: ≥4.5L/min b) Working pressure range: 80kPa～130kPa c) Spray rate: ≥0.2mL/min d) Residual liquid volume: ≤1.8mL e) Continuous nebulization operating time: ≥4h

Indications: Adjuvant respiratory physiotherapy for pulmonary inflammation, airway obstruction, obstructive pneumonia, pulmonary bullae and pulmonary emphysema.

• 11 interchangeable treatment heads of various specifications
• 6 therapy modes for both adults and pediatric patients
• 2-in-1 function: sputum clearance + nebulization
• Large touchscreen with intuitive UI for simple operation
• Comes with operation guide card and user manual
• Enables sputum drainage in vertical, horizontal and multi-angle orientations
